GEAR REVIEW | FROM TAPE OP NO. 122

EHR-M Cardioid Condenser Mic: EHR-M Cardioid Condenser Mic

REVIEWED BY Brad Allen Williams

Nearly all of the condenser microphones we know and love employ round capsules. Notable exceptions include rectangular-capsule Pearl and Milab mics (which, like the Ehrlund, are Swedish in origin), Bock’s Elliptical 5ZERO7, and three Audio-Technica models (which utilize smaller rectangles). I’m certain that diligent research could uncover others, but overall, the circle’s hegemony is strong.

Cymbals, gongs, and drums arealsoalmost-always-round. But while these instruments are designed to resonate when excited, it’s theoretically best if a mic capsule movesonly when directly influenced by sound pressure. Herein lies the logic behind Ehrlund’s triangular condenser capsule.

Anyone who’s ever played one of the old Trixon Speedfire bass drums (whose shape might best be described as the marriage of a triangle and a lopsided egg) likely understands why they were more famous for their looks than their sound. Owing partially to their odd shape, a Speedfire kick doesn’t behave very much like other drums. In general, triangular membranes don’t vibrate the way round ones do â€” impulses decay more quickly. With their fixed-cardioidEHR-M, Ehrlund aims to take advantage of the highly-controlled impulse response that’s inherent in a triangular membrane design.

The novel capsule is mated to high-quality transformerless electronics, and first impressions led us to try them on a classical piano session as a spaced pair, 2 m outside an excellent, recently-rebuilt 1890s Steinway C.

When removed from their modest wooden boxes, the mics present themselves well enough. They’re rather large, and although it’s a common prejudice to conflate weight and quality, theEHR-Mare both well-madeandlightweight, owing to their aluminum bodies and transformerless electronics. For a mic that excels when it’s at (spoiler alert!) moderate distances from the source, this attribute increases flexibility of positioning; even medium-quality stands are unlikely to sag or droop under the weight of anEHR-M.

The sound is â€” in a word â€”different. Broadly, I perceived an extended bottom, emphasized top, and understated midrange. Outside the Steinway, our first impressions were positive indeed; the low-end extension was notable and effortless, and the top-end “reach” was striking. They sounded lovely at this distance!

The authoritative bottom end made me curious to later hear the Ehrlund on upright bass. I was impressed again, and it was once again interesting just howdifferentthe sound was from the vintage Neumann U 47 that often lands on bass at our studio. I remain drawn to the U 47’s large and enveloping rendering of double bass, but theEHR-Mis cool in a different way â€” ample low end, but in a manner that’s uncommonly forward, direct, and focused. The “reach” we noticed on piano seemed here to reach almost inside the carved top of the bass itself. It’s hyperbolic, but I joked that you couldalmostimagine you were listening to the world’s best-sounding bass DI. Out of curiosity, we positioned a vintage brass-capsule AKG C 414 head-to-head with theEHR-Mand tried combining them in mono. Individually, the two were so different that I wondered whether they might be complementary, but it was quickly apparent that the Ehrlund prefers to stand alone. When it does, however, the results are excellent in a manner that, to me, recalls some of the better Telarc Jazz recordings of the compact disc era.

Aside from the double bass, I had less success with theEHR-Min close applications. Contributory to my struggles might’ve been a gap between what I’m used to hearing from a condenser and what this mic delivers (it’s justso different). Despite trying a range of placements and distances, for example, I was unable to get a good result on a vintage Martin acoustic guitar. I couldn’t make the critical midrange to speak in the way I wanted, and I couldn’t shake the perception of a boomy bottom. After verifying that I indeed had the capsule pointed the right direction, I tried every position I could think of (even mic’ng the fingerboard) before switching to the vintage C 414, which gave instant gratification. In hindsight, theEHR-M’s feature set (very open weave on the headbasket grille, lack of a pad, pronounced rising top-end response, and high sensitivity/output) might have been clues that this mic would excel most at moderate distances.

Speaking of that sensitivity â€” a pad of 10 to 20 dB would’ve come in very handy, and would be a worthy inclusion should Ehrlund make a version 2. A short experiment outside kick drum was curtailed because of obvious clipping. A glance at the manufacturer’s published specifications revealed that theEHR-Monly claims a maximum SPL input of 105 dBA, and with no pad between the mic’s capsule and electronics, we quickly moved on.

I remember wishing I had an occasion to try theEHR-Mon pipe organ. I imagine that its bottom and top–end extensions (its response is listed as 7 Hz â€“ 87 kHz!) and detailed rendering of sources at distance could prove advantageous in such an application. And though it would probably be academic in most real-world environments, theextremelyimpressive 7 dBA published self-noise figure certainly would not hurt!

All-in-all, theEHR-Mis a quality microphone that’s almost certainly unlike anything else in the mic locker. If you’re looking for something in the tradition of the classic German and Austrian condensers, this isn’t it. But if you need a mic that excels at distance-mic’ng with focused, articulate rendering of extreme top and bottom (and are willing to embrace a somewhat unusual, restrained midrange), theEHR-Mis a worthwhile and intriguing listen!

$1699 street;www.ehrlund.se –Brad Allen Williamswww.bradallenwilliams.com
